TECHNICAL PARAMETERS
|
Unit Module |
Item |
Parameter |
|
Model Number |
KP-P2-40scan |
|
|
Module size |
320mm*160mm |
|
|
Physical pitch |
2mm |
|
|
Physical Density |
250000 Point/m2 |
|
|
Pixel configuration |
1R1G1B |
|
|
Package mode |
SMD 3IN1 -1515 |
|
|
Video rate |
60Hz |
|
|
Module Resolution |
160dots(W)*80dots(H) |
|
|
Brightness/color uniformity |
98% |
|
|
Max Power |
25W |
|
|
Module thickness |
5mm |
|
|
Module Weight |
340g |
|
|
Drive type |
Constant drive |
|
|
Scan mode |
1/40scan |
|
|
IP Rating |
IP 30 |
|
|
Port type |
Custom |
|
|
Contrast |
5000 : 1 |
|
|
Match Cabinet Size |
W640mm*H480mm W640mm*H640mm |
|
Display Parameters |
Dimension |
640mm*640mm |
|
Thickness |
61.5mm |
|
|
Weight |
6.5kg |
|
|
Monomer Module Number |
8pcs |
|
|
Maintenance Connection Mode |
Pre Maintenance |
|
|
Pixel Per Cabinet |
320x320pixels |
|
Best Viewing Angle |
H:160°;V:140° |
|
|
Recommended Viewing |
2m-12m |
|
|
Driving IC |
ICN/SM/FM |
|
|
Rate Refresh |
≥4200Hz |
|
|
Video support |
2K HD, 4K UHD |
|
|
Bit Depth |
12 -14 bit |
|
|
Color temperature |
2800 – 10000 |
|
|
Brightness Of White Balance |
≥ 600cd/m² ( min/ Max) |
|
|
Operating |
-20°C~50°C |
|
|
Life Time |
>100.000 hours |
|
|
The Rate |
<0.0001 |
|
|
MBTF |
>5000 hours |
|
|
Cabinet Matching Module Size |
320mmx160mm |
|
|
Cabinet Matching Module Model |
P1.25/P1.538/P1.86/P2/P2.5 |
|
|
Power |
Input Voltage |
200-240V;AC±10% 47-63(Hz) |
|
Power Supply |
5V/40A*1 pcs |
|
|
Working Voltage |
AC220V±10% |
|
|
Average Power Consumption |
140w/m² |
|
|
Max. Power Consumption |
410w/m² |
|
|
Control System |
CPU |
Pentium4 or above P4 |
|
Operation System |
WIN98/2000/NT/XP/WIN7 |
|
|
Control Method |
Synchronization |
PRODUCT FEATURES
1. The cabinet is light and thin, with exquisite appearance and uniform color. 2. Rich and full color, high contrast, natural image quality and realistic image.
3. Can achieve high precision CNC, seamless splicing.
4. Low energy consumption, no noise, energy saving and environmental protection. 5. Unlimited layout arrangement, each output daughter board provides 16 layers (up to 16 layers per port)
6. Support input and output signals with full 60FPS smooth processing, no delay or frame loss, fully displaying every detail of the image.
7. High-quality interpolation technology, including adaptive content interpolation processor.
8. Support hot-plug for input and output along with intelligent data recovery function, ensuring safety, stability and convenient operation.
9. Support web and mobile control.
10. Support 3D display.
11. Support self-test to detect errors, along with automatic monitoring and warning. High brightness, High contrast, High refresh rate
12. Full front maintenance, easy management.
13. High refresh rate, wider color gamut, HDR support.
14. 16:9 golden ratio, can freely pair 2K, 4K, 8K and other golden resolutions.
15. Support wall installation
